Neo 350 (2018)

Описание

Specifications

Accommodation

6 sleeping places in 3 cabins.
1 large BSI PORTLIGHTFLUSH hatch pivoting 180° (for sails easy-drop ) in front dinette.
2 BSI PORTLIGHTFLUSH portholes in the back cabins.
1 BSI PORTLIGHTFLUSH portholes in the bathroom.
1 BSI PORTLIGHTFLUSH portholes in the kitchen area.
Pivoting inox kitchen two fires + owen.
Electric toilet; WC RACE STANDARD 24V NERO LUCIDO; KIT CONTROL PANEL TOUCH NERO 2P.
Hot water boiler 10lt , 220v heater , connected with engine cooling system,( external shower pack cancelled deducted 500 euros).
Carbon fiber console on carbon fiber pedestals to allow chartplotter and pilot control ( EACH). (WILL INCLUDE HOLDING TUBES TO AVOID MAINSAIL SHEET IN JYBING).
6 fenders, 3x20mt mooring ropes, carbon fiber flag pole.
2 lavatories in bathroom and kitchen.
1 composite telescopic table in the front dinette with carbon/carbon look ram (up/down).
1 multifunctional chart table.
Extra lockers in the front dinette.
Extra lockers in the back cabin.
Greywaters plastic holding tank.

Construction

Hull, deck, bulkheads, structural interiors and reinforces made out from female moulds with hi density pvc core, unidirectional and multidirectional E-glass fiber with vacuum infused vinilester resin. All materials made in Europe.
Keel and logitudinal reinforcements made out of unidirectional solid E-glass fiber directly vacuum infused in the hull ( postcured at 50°).
Chainplates , forestay and backstay attacks vacuum laminated with unidirectional E-glass directly into the hull internal and external skins. (postcured at 60°).
Titanium fittings for shroud attacks.
Bonded Hull and deck joint with triple tapered bidirectional E-glass fiber banding , with vinilester resin, vacuum and postcured at 50°.
Natural white vinilester gelcoat finishing for hull and deck.
LOFT VERSION all composite interiors made out of lite pvc core and a mix of E-glass structure with vinilester resin postcured at 50°. INCLUDING 6 sleeping places in 3 cabins.
Composites light floorboards white antislip colored.
"Sea dek" superlight , antislip , NO-HEAT, EVA cover in cockpit and seats ( any style and color).
"Sea dek" on internal floorboards and stairway.
3 composite doors white Angel painted.

Equipment

Carbon mast and boom
carbon made look cabin central structures for mast
rod standing rigging complete with barrel-pins and turnbuckles
twin SK 75 spectra backstays, 2:1mainsail halyard , 2 genoa halyards, 2 masthead gennaker halyardsSK 75
Sheets: T mainsails, jib, gennaker , gennaker and code 0 tacks ( dyneema SK 75)
6 proper sized winches Harken performa for : halyards, main sheet, genoa/gennaker halyards,gennaker tack
jib sheet system harken
8 stoppers "spinlock" and 2 "Antal"
Aisi 316 pulpits and stantchions
Dynema SK75 lifelines
1 analogic compass
Inboard diesel engine VOLVO PENTA D1-30 with S-drive trasmission and alternator
2/3 blades foLding propeller
80 lt diesel tank in the lowest possible position for best center of gravity.
12 volt electric installation controlled by SPELL-Advanced 16 channels digital touch-screen .
Led light properly distributed in each cabin
Led lights in the engine room, transom locker, front saillocker
12 volt sockets in each cabin, charttable, front dinette, cockpit
1 engine battery 60 A
1 services battery 150 A
2 manual batteries switches
1 fridge 120 lt
idraulic installation complete with autoclave and flush seacocks
150 lt soft fresh water tanks with external charge
predisposition for grey waters tank
predisposition for hot water
4 foldable superlite alluminium mooring bitts
1 manual bilge pump
3 elettrictric bilge pumps
220 volt land battery charger , 3 x 220 volt internal sockets
certified VHF radio at chart table
DOuble layer authomotive style ( primer, paint,transparent) paintwork on hull (mandatory if Epoxy pack is chosen)
sprayed bolina racing antifouling , 3 hands on adherpox epossidic hand prepared hull
carbon made dinette table
carbon made floorboards
3 carbonmade superlite doors
Tuff luff or harken headstay foil
upgrade to PBO headstay and backstay
Upgrade to prepreg autoclaved carbon fiber rudder , carbon rudder stock , and JP3 or jefa self-aligning ball bearing
Carbon fiber bowsprit for anchor , gennaker and code 0
Carbon spinnaker pole and pole track on mast
Upgrade to composite pulpits and stantchions
Code 0 2:1 dedicated halyard
Upwindstaysail Hook and deck padeye
dyneema lazy jack + lazy bag
Windlass , inox roll adaptor for bowsprit ( or independent if no bowsprit) ,anchor, 30 mt 8mm calibrated chain,10 kg anchor
VTR twin pedestal , Twin carbon wheels 850cm with aluminium sector and vectran cables ( to explore possibility of engine leverage on consolle)

Navigation Equipment

B&G ELECTRONICS (other options available for electronics)
B&G CPU HYDRA 5000
UPGRADE TO HERCULES PROCESSOR
UPGRADE TO PERFORMANCE PROCESSOR
B&G H5000 GRAFIC MULTIFUNCTION DISPLAY
B&G MAXY DISPLAY 20/20 AT MAST 4 pcs
ALUMINIUM 20/20 MAST SUPPORT
COMPASS RC42N
RACING MAST HEAD UNIT 810 mm ,MAST CABLE, SUPPORT FOR MASTHEAD
SPEED SENSOR WITH FLUSH THRU HULL
ECOSOUNDER SENSOR WITH FLUSH THRU HULL
CABLE , JUNK BOXES AND ACCESSORIES FOR INSTALLATION
ZG 100 GPS ANTENNA (FOR CHARTPLOTTER)
ZEUS TOUCH 9" CHARTPLOTTER 2 pcs
AUTOPILOT B&G
H 5000 PILOT CPU
PILOT RAM T1 12VOLT
ROTARY RUDDER SENSOR RF 25N
PILOT DISPLAY H5000
WiFi module
