Mengi-Yay Yachts 40m Extreme (2019)

Description

+972544782931 Константин

[email protected]

L.O.A. 40 m Construction Steel / Aluminum
Year 2019 Cruising Speed 12 Knots
Designer Jaron Ginton Main Engines 2 X 800 hp Caterpillar C 18
Shipyard Mengi Yay Range 3,000 NM
Cabins / Guests 12 Guests at 6 Cabins Class RINA Unrestricted

Designed by Jaron Ginton from The Netherlands, built in 2019 at Mengi Yay shipyard from Turkey.
Interior design was done by Guido De Groot. (The Netherland)

Main Engines 2 X Caterpillar C18 679 hp / 400 hrs. (October 2021)

Gear ZF 550

Generators 2 X Caterpillar C4.4 / 86 kw with 1800 hrs. (October 2021)

Fuel Consumption:

Engine 1500 RPM 45 LPH each / 8 knots at flat sea

Generator fuel consumption 7 – 10 LPH

Generators are synchronized automatically. If one is reaching 70% of its load the other one is kicking in. The system also knows to balance the running hours between both.

Fuel 32,000 Liter

Water – 7,500 Liter

Sewage – 8,200 Liter

Range at 8 Knots 2,500 NM

Water Makers 2 X Hidromar 300 LPH

Air Conditioning CruiseAir system with total 288,000 BTU (4 X 72,000 BTU units)

Rigging

Mast – By DOKAR, Aluminum (painted) inserted into the deck (keel Step)

Four spreaders swept backwards

Total height of mast: 52.8m
